Pneumatic Conveyor Transfer Lift for Automotive Trim Area

Solution: 66
Industry:Automotive Lift and Positioning Equipment
Model: Pneumatic Conveyor Transfer Lift for Automotive Trim Area
Type: Carrier
Actuation: Pneumatic
Dimensions: 270" × 48"
Travel: 26"
Capacity: 10,000 lbs

Overview

This 10,000 lb. capacity lift was used in the final trim area of a luxury car assembly plant.  The lift’s capacity was necessary due to the fact that the conveyor, which was mounted on it, weighed 5,000 lbs. and the car and skid weighed an additional 5,000 lbs.

The high-speed conveyor transferred the car during the final trim assembly, with the lift facilitating the move from an upper to a lower elevation.  This application is especially common in automotive applications which successfully incorporate material handling design with conveyor technology.

Features

  • Vertical air cylinder with built-in redundancy.
  • Pneumatic design.
  • Specialized design for unique conveyor system.
