Multi Stage Scissor Lift for Turbine Assembly

Solution:162
Industry:Material Handling Solutions for the Power-Gen Industry
Model:Custom
Type:Multi Stage Lift
Actuation:Hydraulic
Dimensions:192" × 192" × 347
Travel:252"
Capacity:3,000 lbs

Overview

Handling Specialty was asked to quote on a vertical assembly platform that is being used during the assembly process for large energy turbines. The lift is mounted in a pit and rises approximately 35 feet, safely holding personnel and equipment as the turbine assembly is completed.

The platform features 3 (three) round removable plates, which can be manufactured in a variety of sizes. For safety, the lift also features safety lock-up bars to hold the lift in a raised position for regular maintenance and hydraulic cylinders equipped with velocity fuses to provide a rate of descent protection.

Features

  • Heavy duty scissor lift.
  • 252” vertical travel (21 feet).
  • Raised height 347” from pit floor to platform (approximately 29 feet).
  • Lowered height less than 8 feet.
  • 1.8” per second rise rate, lower rate by gravity (hydraulic cylinders equipped with velocity fuses to provide a rate of descent protection).
